Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 168
Fig. 84. The Doric Order. ARCHITECTURAL DRAFTING 331 … Fig. 85. The Ionic Order. 322 ARCHITECTURAL DRAFTING Fig. 84 shows the Doric Order. This hasa great deal of oriiament, both on the soffit ofthe corona (the projecting, crowning member ofthe cornice), and on the mouldings. In mostmodern designs, we see this Order modifiedmore or less. There are two…
Architectural drawing · Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
