Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 181
lly the beginner is a little backward whenstarting the lettering on a sheet. By practicingvertical lines, inclined lines, and curves, onegradually learns the use of the pen. It should benoted that the strokes are all downward; anda curve, as for O, is made up of a series ofstrokes. There will be… … AECHITECTUEAL DEAFTING 331 pressure as possible. Keep the paper as freefrom erased lines as possible, as the erasingtends to destroj^ the general suiface of thepaper, and makes it much more difficult to inkproperly upon it. Should a mistake be made,after the ink has become thoroughly dry, usean…
Architectural drawing · Architecture
