Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 21
eet of tracingpaper. These may be held down with thumb-tacks or weights of some sort placed on oppositeends. Assume each square of the paper torepresent some unit, as one inch, or one foot, orten feet; and lay out first the property lines.Then commence on the building proper. Makeno attempt at… … ^^AxJrS^CiFtsxr Fig. 2. A Single-Line Sketch Submitted, from which the Archi-tect *€ts an Idea of the Arrangement.
Architectural drawing · Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
