brick, withthe lines running in the opposite direction. For representing an interior partition of aframe building, the method shown in Fig. 6 isperhaps the most satisfactory. Plaster is repre-sented by parallel lines to opposite sides of thewall. Very often, in fireproof buildings, partitionsare… … ,-^-^ -^ri ARCHITECTURAL DRAFTIXG 247 the brick wall, and show the plaster away fromthe wall, as in Fig. 8. Very often, instead of using the partition asshown in Fig. 7, it will be built up solid of plaster2 inches thick with a layer of expanded metalimbedded. This partition is shown in Fig. 9.It…
