Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 92
rig. 24. Fig. 25. Illustrating Conventional Method of Considering Eays of Light inArchitectural Drafting. the light. The idea intended is to produce thesame effect on a drawing that the sun in thisone position would produce on the building.While the sun would actually produce a shadowon one side of…
Architectural drawing · Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
