Fig. 75. Intersection of Circular Cylinder with an IrregularFour-Sided Prism. 97. Intersection of a Cylinder with a Prism. Fig. 75 represents the intersection of a circularcylinder and an irregular four-sided prism.The two are placed in the first angle, the prism … MECHANICAL DKAFTING 113 standing on its base and the axis of the cylinderparallel to both V and H. The intersection in this case will consist ofthree curved lines, one on face AB, one on BC,and the third on CD. The cylinder may be con-sidered as piercing the prism, and points willbe found in which…
