Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 171

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 171
Fig. 101. Frustum of a Cone. the section must be drawn from the givendirections. (e) Draw in oblique projection a right cir-cular cone standing on its base. The diameter … Fig. 102. End View of WoodenBox. Fig. 103. Metal Bathtub. of the base is 2 inches, and altitude is 4 inches. (f) Make the oblique projection of the frustum of a cone, which is shown in elevation
