Fig. 102. End View of WoodenBox. Fig. 103. Metal Bathtub. of the base is 2 inches, and altitude is 4 inches. (f) Make the oblique projection of the frustum of a cone, which is shown in elevation … MECHANICAL DRAFTING 145 in Fig. 101. The axis of the frustum is 3i/^inches long. (g) Draw the oblique projection of awooden box, of which an end view is shown inFig. 102. The length is 12 inches. The box,including the cover, is made of ^i^ch stock,with the ends nailed onto the sides, and the…
