Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 187

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 187
losed ina small freehand circle, and the dimensionplaced between the center and the arc as in Fig.115; otherwise the length of radius should begiven as in Fig. 114, foUowed by the letter R todenote Radius. 158 MECHANICAL DEAFTING When an arc is given, use only one arrow-head. When a number of holes… … rig. 117. Breaking in Two toShow Over-All Dimensions.
