rig. 117. Breaking in Two toShow Over-All Dimensions. … lOth Fig. 116. Dimensioning Holes Equally Spaced around a Circle. Fig. 118. Half-Inch Bolt, withDimensions. Besides the necessary dimensions of all thedifferent parts of the object represented, theextreme outside dimensions should usually begiven. These are known as over-all dimensions,and should…
