Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 233

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 233
ver this lay a sheet of tracingpaper. These may be held down with thumb-tacks or weights of some sort placed on oppositeends. Assume each square of the paper torepresent some unit, as one inch, or one foot, orten feet; and lay out first the property lines.Then commence on the building proper.… … Fig. 2. A Single-Line Sketch Submitted, from which the Archi-tect Gets an Idea of the Arrangement. ARCHITECTURAL DRAFriNC 197 endeavoring to seeuie an ideal arrangement.Make no attempt at trying to show double linesfor wall lines; let it be a free and easy sketchof single lines. Dont be satisfied…

Architecture · Building

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
