Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 295
TO UPf^EQ Fkocrss Fig. 18. Conventional Representation of Flues for Air Supplyand Ventilation. 253 ARCHITECTURAL DRAFTING describe the kind of heat, and go into detailabout pipe, fittings, etc. In hospitals, public buildings, and school-houses, where there are a number of occupantsin each room, it… … Fig. 19. Sketch Plan Showing Arrangement of Furniture. The method of figuring the correct location forsuch work will be considered under Heatingand Ventilating. The conventional method ofshowing flues for air supply and ventilation isshown in Fig. 18. For furniture, certain conventional forms…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
