Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 304
Fig. 24. Fig. 25. Illustrating Conventional Method of Considering Eays of Light inArchitectural Drafting. the light. The idea intended is to produce thesame effect on a drawing that the sun in thisone position would produce on the building.While the sun would actually produce a shadowon one side of…
Architecture · Building
