Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 313
PL.ANFig. 42. Illustrating Principles of Shadows. stated, to each edge of the brick. The top, bot-tom, and side faces of the brick are perpendicu- 268 ARCHITECTURAL DRAFTING lar to the plane, therefore the shadows will berectangular in shape. Pigs. 42 and 43 show a further applicationof the… … CLSVAT/ON S£CT/OA/ Fig. 43. Illustrating Principles of Shadows. Plate D shows the shadows as cast upon anOrder of architecture, illustrating also howmuch clearer the drawing is when it has theshadows worked out on it. The above principles will give a generalunderstanding of the subject. DETAILS OF…
