tment, for,with any setting of the dividers, a slight turnof the screw changes the distance between the 22 MECHANICAL DRAFTING needle-points by a very small amount. Settingup the screw increases the space, while turningthe screw out lessens the distance between thepoints. 37. The small dividers or… … rig. 24. Illustrating Use of Irregular or French Curves. or less in radius. If a number of small circlesof the same size are to be drawn, the setting ismuch less likely to be accidentall}^ changed thanwith the large compass. 39. The bow pen (Fig. 9) is indispensablewhere very small circles are to…
