Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 88
Fig. 54. Drawing Triangular Prism of Fig. 53 in AnotherPosition. tion. That is, for a rectangular object—as acube or a square prism—there may be the topview or plan; the front view or elevation, andthe third, a profile view or end view. The direc-tion of the profile view in comparison with the 66…
Architecture · Building
