Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 284
of juncture of the various members ofthe mouldings do not run in a straight line, thusmaking the miter-joint a httle curved, which ad- PRACTICAL CARPENTRY 249 mits of the mouldings working together accuratelywithout requiring to be pared. Figs. 193, 194, 195, and 196 show how variousjoints are made… … FIQ. 193 jection, as shown at Fig. 197. A shows the springmoulding; B the space left vacant by the leaningof the moulding. These mouldings are difficult tomiter, more particularly so when the joint is madewith a raking moulding that springs also. Someof the methods given for obtaining the cuts for…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
