Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 286
FIG. 195 PRACTICAL CARPENTRY 251 come across very knotty operations of this kind towork out, and the following diagrams will thenprove exceedingly useful: Fig. 198 exhibits an … FIG. 196 elevation of a circular moulding mitered into ahorizontal moulding. The shape and plan of themoulding is shown at B. It is evident that byproducing the Une AD to intersect the center line 252 PRACTICAL CARPENTRY of the arc at C, the central point will be obtained,from which the circular…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
