Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 323
the buttresses, square mild 258 CEMENT CONSTRUCTION steel being used in all cases. Those laid hori-zontally in the face of the wall are of %-in. ma-terial spaced on different centers, farther apartat the top and closer at the bottom, to take careof the increasing pressures toward the bottomof the… … /fV H Fig. 91. Section of Counterfort Fig. 92. Section of Low Wall.Wall Shown in Plate 14. run from the wall into each buttress, two ofthem being looped over every third of the hori-zontal face bars. They are 6 ft. long, and % CEMENT CONSTRUCTION 259 in. square. The heaviest bars used on the…
