Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 101
Fig. 53. rig. 54. Plan and Elevation of Radiator Connected with Swing Joint toEiser to Allow for Expansion—Overhead System of Hot-Water Heating, tees as will bring the centers of the elbows on aline with the centers of the openings in the radi-ators. A plan and elevation of this type ofconnection…
