riousways. Probably the simplest method in connectionwith a steam or hot-water heating apparatus isillustrated in Fig. 112. A pipe riser is carriedup near to the flue, and a branch on each floorrun to a small coil or line of pipe inserted inthe flue above the register. A small air-pipeleading from… … ^cr^f ^li^ay Fig. 112. Placing a Coil in Ventilating Flue to Force Circulation. be found to afford a very satisfactory methodfor securing ventilation. Another method, which may be adopted in adwelling with a large attic, involves having theventilating flues terminate just above the atticfloor,…
