Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 206
Fig. 10. Floor Drain. Fig. 9. Continuous Waste andTrap from Wash Trays. … Fig. 11. Kitchen sink. 176 PLUMBING floor and vent to wall, and nickel-plated Fullerbibbs. The range boiler is shown in Fig. 12. It isto be erected on a stand (Fig. 13), and connectedto the kitchen range, and also to a gas heater asshown in Fig. 14. The first-floor lavatory (Fig. 15) is fittedwith…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
