Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 225
ools shown in Fig. 36 will be found very useful. Fig. 37 shows a waste and vent fitting that 192 PLUMBING can be used where two fixtures are set back toback. Figs. 38, 39, and 40, show various styles ofroof-flashings. Figs. 41 and 42 show various styles of in-creasers, which are used at a point… … Fig. 45. Brass Bath Trap for Wrought-Iron Waste Work. Fig. 44 shows one style of tapped tee. Fig. 45 shows a brass bath trap that is usedwhere the waste work is all wrought iron—or,as it is sometimes called, the Durham system. Water-Service Pipes. We shall now takeup the water supplies to the…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
