a single fixture as shown in Fig.74. The good points of this style of work can bereadily noted. 258 PLUMBING Fig. 76 shows the ordinary method of vent-ing a number of closets. A comparison of Fig. 72 with Fig. 76 willshow many superior points in the latter. Fig. 77 is an end elevation of the closet… … Fig. 77. End Elevation of Closet Stalls.Flush tank to each closet. Fig. 78 shows a side view of the urinals.The system of waste- and vent-piping is shownin Figs. 74 and 75. There may be a single automatic flush-tankfor each urinal; or one flush-tank for the liatteryof urinals; or each urinal may be…
