Mechanical drawing for plumbers; a concise, comprehensive and practical treatise on the subject of mechanical drawing (1910)
Starbuck, R. M. (Robert Macy), 1844-1927 · New York, The Norman W. Henley publishing co. · leaf 84
the points on the roof wherethe several stacks come up being shownby the letters A, B, C, and D. This latterinformation will be valuable in figuring stack, as the vertical runs of pipe canbe found by noting at what heights thestacks come through the roof. We would advise the student to practiceon… … CoTt-C.TCt.ti/ *£\XXfcB^ £»J^LD CE»X_»Xu£^R. WajTIES. CLOSET. CHAPTER XIX TO complete the elevations showingthe plumbing work of the resi-dence which was taken up inthe chapter preceding this, wehave prepared Figs.- 8, 9 and 10. Fig. 9 the method shown in the elevations of thelast article. While in…
Plumbing · Mechanical drawing
