Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)

Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 92

An illustration from Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work, 1909, leaf 92
ATING AND VENTILATION 71 TABLE IVExpansion Tanks Squ iRE Feet OF Radiation Size of Tank Capacity Provided for 12x20 inches 10 gallons 200 to 400 12x30 15 500 * 60U 14 x30 20 700 800 16 X 30 26 900 1,200 16x36 32 i,300 1,800 16x48 42 2,000 2,500 18x60 66 3,000 • 4,000 used, there would be danger of… … overflow Fig. 42, Automatic Expansion Tank Allowing Drawing-OfE of HotWater from the System. from the system without suffering the above dis-advantage, an automatic tank of the type shovv^nin Fig. 42 should be attached to the plant. Thewater supply to this tank is controlled by a ball-cock and…
