Radford's cyclopedia of construction; carpentry, building and architecture. Based on the practical experience of a large staff of experts in actual constrcution work (1909)
Johnson, Alfred Sidney, 1860-, Radford, William A., 1865- · Chicago Radford Architectural Co · leaf 94
Flow R<Ztur/t Fig. 44. Connections of First-Floor Hot-Water Radiator whenBranch Feeds Also a Riser. HEATING AND VENTILATION 73 Hot - Water Radiator Connections. The usage of the double-swing or expansion joint, towhich attention was called in discussing the con-nection for steam radiators, is… … 4^ ^7izsc,r<s>^frvm Fig. 45. Showing How Tliird-Floor Hot-Water Radiator ts Con-nected to Side of Riser Feeding Second-Floor Radiator. the extra elbows. Fig. 43 shows the ordinarymethod of joining a hot-water radiator to theflow and return mains, this connection beingmade in as direct a…
Architecture · Building
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
