Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 149
Fig. 93. Radiator Connected with Hori zontal Flow and Return Mains Located below Floor. Fig. 94. Radiator Connected to VerticalRiser and Return Drop. For example, if in the case of Fig. 90 we assume the water toleave at 180 degrees and return at 160, we shall have a drop in tem-perature of 10…
