GoodConstruct^ PLATE 132—FAULTY VS. GOOD CONSTRUCTION At A and B are shown methods of sill wind stops. At C and D are shown forms construction. At A the masonry projects be- of construction at the bearing of the second floor yond the base-board—conducive to dampness; joists. C is the usual method…
