Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 162
water. The concrete arch cover-ing the cistern may be built up over a sand core,though this means considerable labor in shovelingout the sand through the manhole after the con-crete has set. A flat slab four inches thick andstrongly reinforced with steel rods or reinforcingfabric makes a good… … PLATE 148—ICE CHEST AND MILK COOLER Cross section showing details of construction of flooring, two quarter inch air spaces, one half a very efficient milk cooler for dairies, creameries inch of hair felt and two thicknesses of insulating and milk shipping stations. The insulated walls paper. The…
