Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 176
ll PLATE 162 B—CONCRETE SEPTIC TANK Arrangement and details for home-made septic material is broken down into gas and clear harm-sewage disposal system. B is the first cham- less liquid which flows away intermittentlyber and receives the crude sewage which enters through chambers C and D into the… … PLATE 162 A—SEPTIC SEWAGE DISPOSAL Sectional drawing showing arrangement of In country and suburban places away from reg- modern septic tank with filter bed, together with ular sewage systems the septic tank method is arrangement and proper connections for house the only sanitary arrangement for…
