Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 188
THE BOSTON HIP The sketch shows a shingled hip viewed fromabove. It is formed by laying a double row ofshingles lengthwise along the hip, fitting themcarefully so as to make a water tight job. Thesehip shingles are nailed on after all the rest ofthe shingling is done. The middle joint alter-nates…
