Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 39
FLOOR CONSTRUCTION AND SUPPORT IN FIRERESISTING MILL BUILDING. PLATE 28B—FIRE RESISTING TIMBER FACTORY CONSTRUCTION Details of approved or standard mill and warehouse framing. … PLATE 28A—BRICK VENEER CONSTRUCTION Details of double hung windows with outside screens; also details of door jamb, all using brick veneer. rw* <(a**rmi *s0*k
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
