Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 82
?KOH. PLATE 70—OUTWARD OPENING CASEMENT—ORDINARY CONSTRUCTION Arrangement ordinarily used in frame dwell-ings. Fig. 150, section through window head.Note flashing of tin, or in better work, copper.Fig. 151, section through window jamb. Notethat inside stop bead is hollowed at H to form achannel…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
