Radford's portfolio of details of building construction : a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale ... (1911)
Radford, William A., 1865-, Johnson, Bernard L, Rawson, Charles P · Chicago : The Radford Architectural Company · leaf 91
TSIDE SCREENS AND BLINDS Construction in brick wall. Fig. 182, section and is so arranged that storm sash can be hung in through window head. Pig. 183, section through its place during cold weather. Fig. 184, section jamb; note effective water-proof joint between through sill showing arrangement to… … &roti-Et hu*u. 6 ■■■■ XG,. 190. PLATE 79—INWARD OPENING CASEMENT BAY WINDOW Construction in masonry wall. A popular and through window sill. Pig. 190, enlarged plan very satisfactory window arrangement. The ex- view and horizontal section taken through the terior elevation shows the design; the…
Building · Architecture
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
