Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)

Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 117

An illustration from Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art, 1922, leaf 117
insulate and fasten the farther end or freeend of a sing:le wire antenna. moulded right into the brown insulating material. Theinsulator proper is provided with many deep grooves, soas to lengthen the surface of the insulator and thereforeincrease its resistance to leakage or loss. Small… … No. 14 CopperTie Wire Insulator No. 14 Insulated ,^^^/Copper Wire How the nearer end or lead-in end of the antenna is fastened and insu-lated. The lead-in w^ire is fastened to the antenna wire by means of a connector, or is soldered so as to insure a perfect and lasting joint. RADIO FOR EVERYBODY…
