Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 336

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 336
frame. The bridge is 160 feet on the long span and 100 feet on theshort span. Balanced on friction rollers by counterweights and oper-ated by electric motor. Plan and elevation. BUTTONROPE SMAIN CABLE TRAVERSING … 856. FALL ROPECABLE CARRIER. Miller type. Five-ropesystem without fall latch.The power of the hoistrope is increased threetimes at the fall block. 857. Section of a per-manent button stop withpin and holes for soldering. THE BUTTON

Mechanical movements
