Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)

Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 119

An illustration from Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art, 1922, leaf 119
n poles orsupported by the dumbwaiter houses on the roof. Finally,the author simply ran a single wire down a chimney, fromthe roof to the cellar, a distance of about 75 feet. Thiswire was never detected, and it was tapped in the kitchenof the apartment, through a flue that led into the chimney.A… … T-TYPE ANTENNA, TAPPED IN CENTER Arrangement of a T-type single wire antenna. When the antenna runs longer than 150 feet, it may be desirable to tap it in the center for the lead-in, provided the lead-in can be dropped straight down to the receiving apparatus. telephone line with a fixed condenser…

Radio
