Radio for everybody; being a popular guide to practical radio-phone reception and transmission and to the dot-and-dash reception and transmission of the radio telegraph, for the layman who wants to apply radio for his pleasure and profit without going into the special theories and the intricacies of the art (1922)
Lescarboura, Austin C. (Austin Celestin), 1891- · New York, Scientific American publishing company [etc.] · leaf 257
^38 RADIO FOR EVERYBODY dependent entirely on the constants or electrical values ofthe circuit. Perhaps the accompanying diagram makesthe foregoing description clearer. It will be noted that thearrangement here shown is very mUch like the usual regen-erative receiving hook-up, except that the… … rr vc, n G Simple CW telegraph transmitter whichmay be assembled by any one. A—aerial;G—grround; P and S>^primary and sec-ondary of the loose-coupler LC; VCl—variable condenser for reducing wavelength of aerial-ground circuit if neces-sary; VC2—variable condenser; OT—oscil-lating tube;…
Radio
