Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 128

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 128
I … Fi^. 180 Fti. J8I now insert a file in the hole, keeping one side square withthe saw cut; now place the block on the tooth edge. Fig.181, of the saw blade, and by running it from end to endall the teeth may be jointed to a uniform length. CHAPTER XV. To Fhtd the Cut on the Square of any Angle—To…

Carpentry

Internet Archive · Boston Public Library · Public Domain Mark 1.0. Free to use for anything.
