Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)
Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 131
ard,3lS a b and c d—say half an inch apart; then, with a c asradius, draw the arcs, as shown, with the centres on thelines a b and c d; then bore the holes i, 2, 3, 4 in board e, 124 GUIDE AND ASSISTANT using an inch bit, and trim the dovetails 5, 6, 7, 8 ; i, 2, 3, 4is the dovetail of board f and… … Fig isr n u inside blinds for cutting them in two : After they are hungshut them together and mxark on the edge of the meeting-stiles the centre of the meeting rail, as a in Fig. 186; shuteach flap together and square the mark over to the hang-ing stiie, as d, Fig. 187; then open the flap and with…
Carpentry
