Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc. (1894)

Richey, H. G. (Harry Grant), b. 1868 · New York : W.T. Comstock · leaf 20

An illustration from Richey's guide and assistant for carpenters and mechanics : a work of practical information, giving almost every geometrical and practical problem likely to arise in the work of the carpenter, and quick and easy methods for their solution : the use of the steel square, etc., tables showing strength and weight of materials, methods of framing, useful recipes, etc., etc., 1894, leaf 20
ually.6—To Find Length ofSills for Bay Windows.—Following is shown a bay win-dow. Fig. 6. Sometimes it isvery hard to get the length ofthe sills. Now we have the length of the side andend sill as if they ran straight through, as shown bythe dotted lines, but what we want is the length frompoints I… … Fli.3

Carpentry
