Fig. 53 50—To Draw a Pentagon when One Side isGiven.—With a b as base and radius and a b as centres.Fig. 53, strike the circles c d and c f; then draw the per- 44 GUIDE AND ASSISTANT pendicular connecting i and 3; then, with 3 as centre,strike the circle da 2 b f, thus giving points d 2 and f;then…
