80; thendraw the diagonals intersecting at g and Ji; then, with / jd as centre and f a 2,s radius,draw arc a b; then, with e ascentre and same radius, drawarc c d; then, with h as centreand // b as radius, draw arcb d; then, with g as centreand same radius, draw arca c, conipleting the curve. 76—To… … Fig. SI FOR CARPENTERS AND MECHANICS. 6r parts, as i, 2, 3, etc.; draw lines from c and b throughI, 2, 3, etc., and the intersections, as shown, are the pointsof the curve. 77—With the Axes, as a c and d e, of an EllipseGiven, to Draw the Curve.—Place the axes at rightangles to each other, as in…
