The Roentgen rays in medicine and surgery as an aid in diagnosis and as a therapeutic agent : designed for the use of practitioners and students (1901)
Williams, Francis H. (Francis Henry), 1852-1936 · New York, Macmillan · leaf 83
e held firmly in taper plugs in hard rubber insulating plates ateach end of the tube box, and simply rest in contact with the tube terminals. CC, supports for tube;DD, clamps for tube; E, inlet tube for cooling water; F, outlet tube for cooling water; DB, bars toallow CC, the supports, to slide for… … Fig. 43. This cut shows the box devised by Dr. Rollins, with some slight modifications which I have made.This box has a hinged instead ot a sliding cover. It has also a sliding diaphragm. Lines aremarked on the inside of the box, on either side of the hole cut in the cover and on the bottom.…
Radiography · X-rays
