Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 107
through point 2 parallel tothe horizontal axis ab will intersect at point 3 andthus complete one face of the cube b-2-3-1. Now, through the point 4 draw a vertical lineparallel to bd and through point 2 draw a line in-clined 45° with the horizontal ; these two lines intersect at the point 5 and… … Fig. 223. Next draw through tlie point 4 a horizontal lineand parallel to ab and through the point i a line in-clined at 45° and parallel to be ; these two lines cutat the point 7 ; join the points 6 and 7 by a straightline and cube is complete. ROGERS DRAWING AND DESIGN. 123 In Fig. 222 is shown…
Mechanical drawing · Machine design
