Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)

Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 112

An illustration from Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc, 1913, leaf 112
230, 231, and 232 represent addi-tional illustrations of objects drawn in cabinet pro-jection. Note.—The thorough knowledge of cabinet and isometric projec-tions will be of great advantage, both to the student and the mechanic,as they will thereby be enabled to represent different objects in… … Fia. 229.

Mechanical drawing · Machine design
