Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1911)

American School (Lansing, Ill.) · Chicago : American school of correspondence · leaf 302

An illustration from Cyclopedia of textile work : a general reference library on cotton, woolen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects, 1911, leaf 302
color and quality preferred for the round-and-round work; and the inclined lower sideof the lug rides down over the pin, the lugthen snapping under it, ready for the next operation. The picking-finger is left turned upward; but, therebeing no needles with their heels in a plane to be engaged by… … Fig.163. 267 250 KNITTING 149,150, and 164). To this disc are attached two similar ears 172, theoperative surfaces of which are offset. The lever 156, which operates the lift-rod, is pivoted on shaft 26,and has its front beveled end 176 in the path of movement of cams 173and 175. Cam 173 imparts…

Textile fabrics · Textile industry

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
