Rogers' drawing and design; an educational treatise relating to linear drawing; machine design; working drawings; transmission methods; steam, electrical and metal working machines and parts; lathes; boiler and parts; instruments and their use; tables, etc (1913)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 113
considerable distance, hewill see only one side, in this case only the frontside of the cube. The rays of light falling upon the cube are re-flected into the eyes of the observer, and in thismanner he sees the cube. The pane of glass, evi- dently, is placed so that the rays of light from theobject… … Fig. 2:«. a square) which is the view of the object as seenfrom the front. This view is called the front eleva-tion. - One view, however, is not sufficient to show thereal form of a solid figure. In a single view two ROGERS DRAWING AND DESIGN. 129 dimensions only can be shown, length and…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
