(a) — Showing Plan and Front Views Folded intothe Plane of the Side View. … (b) —Showing Front and Side Views Folded into the Plane of the Plan View.Fig. 52. — Various Arrangements of Views. from one view to another, points which are projections of a singlepoint on the object represented. They are the same length as theprojecting rays of light and represent them on the…
